TaskTonic Store for Reactive Data Management

TaskTonic Philosophy

In complex, asynchronous systems, maintaining a consistent, thread-safe application state is one of the greatest challenges. The TaskTonic Store module provides a centralized, hierarchical, and reactive data engine. The module consists of two complementary core components:

  1. Store: The pure, functional, thread-safe data core. It handles hierarchical storage, lock management, MQTT-style wildcard pub/sub notifications, and atomic updates.
  2. Item: A highly powerful, cursor-like view/pointer that references a specific path within the Store. This enables relative navigation, local mutations, and isolated subscriptions.

Within the framework, the store is exposed as a Singleton Service via the ttStore class, accessible in your Tonics via self.ledger.formula.

1. Core API & Data Access

TaskTonic provides multiple ways to interact with data, balancing performance and developer convenience. Using the store is a bit like using a python dictionary but with hierarchical paths and strongly optimised for storing and distributing data in een reactive systems.

1.1 Dictionary Syntax ([])

For quick, intuitive access, both the Store and Item objects fully support standard Python dictionary bracket syntax. Reading missing paths natively returns None instead of raising a KeyError.

# Writing data
store["machine/status"] = "operational"
store["machine/metrics/temperature"] = 22.5

# Reading data
current_status = store["machine/status"]

1.2 The get and set Method

If you want to read a value and provide a fallback if the path doesn't exist, use .get().

# Returns 60 if 'machine/metrics/speed' is not found
speed = store.get("machine/metrics/speed", default=60)

Setting data, single line or multipole line, can be done using set.

        # one item
        self.store.set('setting/ui/background', 'blue')

        # multiple items by dict
        self.store.set({
            'setting/ui/font', 'arial',
            'setting/ui/font_size', 10,
        })

        # multiple items by tuple of tuples
        self.store.set((
            ('setting/ui/font', 'arial'),
            ('setting/ui/font_size', 10),
        ))

If you need to read or write to the same path repeatedly (e.g., inside a rapid timer loop), parsing the path string every time via store["path"] is inefficient. Instead, use .at() to generate an Item cursor.

Storing this Item in a variable creates a live link to that location in the store. You can read/write its value directly via the .v property, or use it to navigate relatively.

from TaskTonic import ttTonic

class DisplayTonic(ttTonic):
    def ttse__on_start(self):
        # Create a cursor to a specific branch
        self.ui_settings = self.ledger.formula.at('settings/ui')

        # Dictionary syntax writes relative to the cursor
        self.ui_settings['background'] = 'blue'

        # .v property writes directly to the cursor's path
        self.ui_settings.at('opacity').v = 0.8

2. Hybrid Nodes & Smart Lists

Traditional data structures force a node to be either a value (a leaf, like a string) or a container (a map or folder). The TaskTonic Store breaks this dogma by introducing Hybrid Nodes.

Every path in the Store can simultaneously hold a direct value and harbor sub-paths (children).

2.1 The Auto-Increment (#)

If you store a standard Python list in the Store and append to it, the Store will not know its contents changed, and subscriptions won't trigger.

TaskTonic uses Smart Lists (Dictionaries with auto-incrementing keys). The # symbol instructs the Store to scan the active list, determine the highest numeric index, increment it by 1, and create a brand new item. Because every item gets an absolute path (e.g., users/#1/name), retrieving deep data is a direct O(1) lookup.

2.2 The "Sticky" Index (.)

The . symbol refers to the most recently generated index by that specific cursor. This is essential for adding multiple properties to the exact same newly created list item without looking up its generated index.

2.3 Creating Valueless Container Lists

Often, you want to create a list of complex objects where the index itself (e.g., #0) doesn't hold a direct value (its .v is None), but acts purely as a container for children.

To achieve this, simply target the child property directly during creation, rather than assigning a value to the #.

class UserManager(ttTonic):
    def ttsc__add_users(self):
        users = self.ledger.formula.at('settings/users')

        # METHOD A: Direct assignment to a sub-property
        # Notice how 'users/#0' has no direct value, but acts as a container for 'name'
        users.set('#/name', 'Bob')     # Creates index #0
        users.set('./role', 'Admin')   # Adds 'role' to #0
        users.set('./age', 32)         # Adds 'age' to #0

        # METHOD B: Atomic batch creation using `set()` and a tuple of tuples
        # This prevents triggering multiple incomplete notifications during setup
        users.set((
           ('emp#', 'New Employee'),   # Creates 'emp#0', where .v = 'New Employee'
           ('./department', 'Sales'),
           ('./salary', 50000),
        ))

2.4 Custom Prefixes (prefix#)

As seen in Method B above, you can segregate different entities within the same tree branch by placing text before the # symbol. Each prefix maintains its own independent counter.

users.set('guest#/name', 'Charlie')  # Becomes: users/guest#0/name
users.set('guest#/name', 'Dave')     # Becomes: users/guest#1/name

3. Navigating the Tree (Item Methods)

Once you hold an Item cursor, you can navigate up, down, and across the data tree efficiently.

  • .parent: Returns a new Item pointing exactly one level up to the parent container.
  • .list_root: Recursively navigates up the path tree to identify the nearest list-container (identifiable by the # syntax). This is crucial within callbacks to find the surrounding entity of a mutated child property.
  • .key: Returns the last segment of the path (e.g., #0 or brightness).

3.1 The children Iterator

To loop over elements in a container, use the .children() method. This returns a memory-efficient Iterator of Item cursors (lazy evaluation).

sensor_container = store.at("sensors")

# Efficiently iterate without loading the entire tree into memory
for child_item in sensor_container.children():
    if child_item.get("status") == "critical":
        # Handle critical sensor...
        pass

While the strict hierarchical tree is great for data integrity (the "Canonical State"), you often need to view data functionally (as a Graph). TaskTonic provides Symlinks to solve this via the .link_to() method.

A passive link acts as a transparent shortcut. It delegates reads and writes to the target. Events bubble up the target's physical tree, but do not bubble up the alias tree (preventing UI event storms).

class HouseController(ttTonic):
    def ttse__on_start(self):
        # Canonical state
        self.ledger.formula.set("devices/lamp#/brightness", 0)  # creating lamp#0

        # Functional grouping (Passive link)
        room_lamp = self.ledger.formula.at("house/living/main_light")
        room_lamp.link_to("devices/lamp#0", bubble_events=False)

        # Writing to the alias automatically routes to devices/lamp_1
        room_lamp["brightness"] = 80

Active links are two-way connections. If the physical target changes, the Store automatically injects a cloned event into the alias tree. Use this for sensors where a room-controller needs to be actively notified of hardware triggers happening deep in the device tree.

sensor_alias = self.ledger.formula.at("security/front_door")
sensor_alias.link_to("devices/motion_1", bubble_events=True)
# Now, if devices/motion_1 triggers, the 'security/front_door' path
# will also bubble the event to any active subscribers.

5. Batch Iteration (set_each)

When updating a collection, doing it item-by-item triggers redundant pub/sub notifications. .set_each() iterates over children and updates them inside a single atomic group().

class LightingTonic(ttTonic):
    def ttsc__turn_off_all_lamps(self):
        living_room = self.ledger.formula.at("house/living/lamps")

        # Resolves through any StoreLinks and fires ONE batch notification
        living_room.set_each("power", "off", prefix="lamp")

6. Advanced Reactivity & Pub/Sub Patterns

The subscribe method is the core of TaskTonic's reactivity. It connects data changes to your Tonic's Sparkles (ttse__).

Your event sparkle will receive a list of updates. Each update is a tuple: (path, new_val, old_val, source_id).

6.1 Exact vs. Recursive Subscriptions

  • Exact: Triggers only on the specific path.
  • Recursive: Triggers on the path AND any of its nested children.
class ProfileWatcher(ttTonic):
    def ttse__on_start(self):
        profile = self.ledger.formula.at("user/profile")

        # Trigger on ANY change inside the profile (name, age, settings)
        profile.subscribe(self.ttse__on_profile_update, recursive=True)

6.2 MQTT-Style Wildcards (* and **)

Subscribe to dynamic paths without knowing the exact IDs upfront: * * (Single-level): Matches exactly one path segment. * ** (Multi-level/Recursive): Matches all deeper path segments.

class SensorDashboard(ttTonic):
    def ttse__on_start(self):
        store = self.ledger.formula

        # Matches 'sensors/kitchen/temp' but NOT 'sensors/kitchen/temp/calibration'
        store.subscribe("sensors/*/temp", self.ttse__on_temp_change)

        # Matches ANY error deep inside the system tree
        store.subscribe("system/**/error", self.ttse__on_system_error)

6.3 Atomic Snapshots (extract and trigger_now)

Instead of receiving raw single-property events (which can cause UI stuttering), request a flat dictionary (snapshot). Use . inside the extract list to retrieve the value of the base path itself.

  • extract: A list of relative properties to fetch simultaneously.
  • trigger_now=True: Immediately fires a synthetic init event upon subscription. Perfect for rendering UI lists without manually polling the Store first.
class UIRenderer(ttTonic):
    def ttse__on_start(self):
        # Subscribe to all widgets, grab their state instantly, and build snapshots
        self.ledger.formula.subscribe(
            "ui/widgets/*",
            self.ttse__render_widget,
            extract=[".", "color", "visible"],
            recursive=True,
            trigger_now=True
        )

    def ttse__render_widget(self, events):
        for path, snapshot, old_val, source in events:
            # Snapshot is safely pre-assembled: {'.': 'button', 'color': 'red', 'visible': True}
            widget_type = snapshot.get(".")
            color = snapshot.get("color")
            self.log(f"Rendering {widget_type} at {path} in {color}")

6.4 Lifecycle Management (Safe Unsubscribing)

Subscriptions are automatically linked to their owner (the instance that created them). Never unsubscribe by path; always unsubscribe by owner to safely clean up your component.

    def ttse__on_finished(self):
        # Removes ALL subscriptions globally where this Tonic is the owner
        self.ledger.formula.unsubscribe(self)

7. Context Managers (group and source)

  • group(source_id=None, notify=True): Batches multiple updates. Listeners are only notified once the block ends.
  • source(source_id): Tags updates with an origin ID. Vital for bidirectional UI sync to prevent infinite loops (listeners can use ignore_source to drop events they caused themselves).
class VolumeSlider(ttTonic):
    def ttse__on_start(self):
        vol_item = self.ledger.formula.at("audio/volume")
        # Listen to the store, but ignore updates tagged with "my_slider"
        vol_item.subscribe(self.ttse__on_external_change, ignore_source="my_slider")

    def ttse__on_user_drag(self, new_value):
        # Write to the store, tagging the source so we don't trigger ourselves
        with self.ledger.formula.source("my_slider"):
            self.ledger.formula.set("audio/volume", new_value)

8. Store API Reference

Core Methods on Store

at(path: str) -> Item

Returns an Item cursor pointing to the specified absolute path.

set(path_or_data: Union[str, dict, tuple], value: Any = None, notify: bool = True) -> Item

Writes data to the root level. Supports single strings, dictionaries, or tuples of tuples. * Returns: The Item cursor of the root.

get(path: str, default: Any = None) -> Any

Retrieves a value by its absolute path. Resolves through StoreLinks automatically.

subscribe(path: Union[str, List[str]], callback: Callable, ignore_source: str = None, recursive: bool = False, exclude: List[str] = None, extract: List[str] = None, trigger_now: bool = False, owner: object = None)

Registers a listener. * path: String or list of absolute paths. Supports * and ** wildcards. * callback: The ttse__ method to execute. * ignore_source: Drops events originating from this source_id. * recursive: If True, catches changes in all descendant paths. (Required if using extract). * exclude: List of absolute sub-paths to ignore. * extract: List of relative child properties to return as a flat snapshot dictionary. * trigger_now: Immediately fires an init event with current data. * owner: The object owning this subscription (auto-detected if a bound method is passed).

unsubscribe(target: Union[Callable, object, List[Any]])

Removes subscriptions. Pass the specific callback function, or the class instance (self) to wipe all subscriptions owned by that instance.

Core Methods on Item (Cursor)

Properties

  • .v: Property to get/set the value of this path. Writing triggers notifications.
  • .path: Absolute path string.
  • .parent: Returns an Item pointing one level up.
  • .list_root: Walks up the path tree to find the nearest ancestor created as an auto-increment list item (#0, user#1). Returns None if not in a list.
  • .key: Returns the last segment of the path (e.g., #0 or brightness).

set(data: Union[str, dict, tuple], value: Any = None, notify: bool = True) -> Item

Writes data relative to this cursor. Fully supports # and . smart syntax. * Returns: Itself, for method chaining.

get(key: str, default: Any = None) -> Any

Dictionary-style lookup for children relative to this cursor.

append(prefix: str = None) -> Item

Explicitly creates a new auto-incremented child item. * Returns: An Item pointing to the newly created element.

extend(data_list: List[Any], prefix: str = None) -> Item

Appends multiple items to the list. If data_list contains tuples of length 2, it builds structures instead of flat values.

pop(subpath: str = None) -> Any

Removes the node (and all descendants) and returns its base value. Operates relative to the cursor if subpath is provided.

remove(subpath: str = None)

Deletes the node and all descendants without returning the value. Safely handles StoreLink cleanup (cascading
